Need Assistance with Data Action

Data Actions
1

I am trying to create a data action to get the supervisor name using Genesys API
/api/v2/users/{userId}/superiors. But when I run the data action, I am getting an error stating: 13. Flatten: Too many results matched criteria.
If I uncheck the box to flatten output", the data action works fine and I get the intended result.

I tried to resolve the issue by updating the translation map as follows:

{
"translationMap": {"name": "$.['name']"},
"translationMapDefaults": {},
"successTemplate": "{\n "name": ${successTemplateUtils.firstFromArray("$.['name']","${esc.quote}UNKNOWN${esc.quote}")}\n}"
}

I then received an error stating: 9. Resolve translation map: Failed while processing the translation map. Could not resolve value for the key: 'name' and no default value was configured. Additional details: Expected to find an object with property ['name'] in path $ but found 'java.util.ArrayList'. This is not a json object according to the JsonProvider: 'com.jayway.jsonpath.spi.json.JsonSmartJsonProvider'.

Appreciate any help you can provide with this.

Here is the JSON request:

{
"name": "Get Agent Supervisor (Copy) - Exported 2024-10-30 @ 7:48",
"integrationType": "purecloud-data-actions",
"actionType": "custom",
"config": {
"request": {
"requestUrlTemplate": "/api/v2/users/${input.userId}/superiors",
"requestType": "GET",
"headers": {
"content-type": "application/json"
},
"requestTemplate": "${input.rawRequest}"
},
"response": {
"translationMap": {},
"translationMapDefaults": {},
"successTemplate": "${rawResult}"
}
},
"contract": {
"input": {
"inputSchema": {
"title": "userId",
"type": "object",
"properties": {
"userId": {
"type": "string"
}
},
"additionalProperties": false
}
},
"output": {
"successSchema": {
"title": "name",
"type": "array",
"items": {
"title": "Item 1",
"type": "object",
"properties": {
"name": {
"type": "string"
}
},
"additionalProperties": true
}
}
}
},
"secure": false
}

Here is the output:
[
{
"id": "650902af-7e78-47db-b165-14ab2eb97004",
"name": "xxxxx xxxxxx",
"chat": {
"jabberId": "xxxxxxxxxxxxx@xxxxx.xxxxxx.com"
},
"department": "Service Operations",
"email": "xxxxxxxx@xxxxxxx.com",
"primaryContactInfo": [
{
"address": "xxxxxxx.xxxxxx@xxxxxxx.com",
"mediaType": "EMAIL",
"type": "PRIMARY"
},
{
"address": "+1xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "PRIMARY"
}
],
"addresses": [
{
"address": "xxxxx.xxxxx@xxxxxxx.com",
"mediaType": "EMAIL",
"type": "WORK"
},
{
"address": "+1xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "WORK",
"countryCode": "US"
},
{
"address": "+1xxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "WORK2",
"countryCode": "US"
},
{
"address": "+1xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "WORK3",
"countryCode": "US"
}
],
"state": "active",
"title": "xxxxxxxxxxxx",
"username": "xxxxxxxxx@xxxxxxx.com",
"manager": {
"id": "15216105-d9dd-4e66-9b58-6d74f1b129eb",
"selfUri": "/api/v2/users/15216105-d9dd-4e66-9b58-6d74f1b129eb"
},
"version": 27,
"acdAutoAnswer": false,
"selfUri": "/api/v2/users/650902af-7e78-47db-b165-14ab2eb97004"
},
{
"id": "15216105-d9dd-4e66-9b58-6d74f1b129eb",
"name": "xxxxxxx xxxxxxxxx",
"chat": {
"jabberId": "xxxxxxxxxxxxxx@xxxxxxxx.orgspan.com"
},
"department": "Service Operations",
"email": "xxxxxxx@xxxxxx.com",
"primaryContactInfo": [
{
"address": "xxxxxxx.xxxxxxx@xxxxxxx.com",
"mediaType": "EMAIL",
"type": "PRIMARY"
},
{
"address": "+1xxxxxxxxxx",
"mediaType": "SMS",
"type": "PRIMARY"
},
{
"address": "+1xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "PRIMARY"
}
],
"addresses": [
{
"address": "xxxxxxx.xxxxxxx@xxxxxxx.com",
"mediaType": "EMAIL",
"type": "WORK"
},
{
"address": "+xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "SMS",
"type": "MOBILE",
"countryCode": "US"
},
{
"address": "+1xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "WORK",
"countryCode": "US"
},
{
"address": "+1xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "WORK2",
"countryCode": "US"
},
{
"address": "+1xxxxxxxxxx",
"display": "+1 xxx-xxx-xxxx",
"mediaType": "PHONE",
"type": "WORK3",
"countryCode": "US"
}
],
"state": "active",
"title": "xxxxxxxx xxxxxxxx",
"username": "xxxxxxx@xxxxxxx.com",
"manager": {
"id": "ec63e2cf-0b6a-4c59-8adf-f67fe423ed58",
"selfUri": "/api/v2/users/ec63e2cf-0b6a-4c59-8adf-f67fe423ed58"
},
"images": [
{
"resolution": "x48",
"imageUri": "https://api-downloads.usw2.pure.cloud/directory-profile/49431f39/0625/46da/8fd1/a9f7dbb70d20.jpg"
},
{
"resolution": "x96",
"imageUri": "https://api-downloads.usw2.pure.cloud/directory-profile/d1482ce4/cf6e/439a/9371/26f37dc5cc59.jpg"
},
{
"resolution": "x128",
"imageUri": "https://api-downloads.usw2.pure.cloud/directory-profile/5812f5d9/dd6c/45fa/a826/b5f0614c8883.jpg"
},
{
"resolution": "x200",
"imageUri": "https://api-downloads.usw2.pure.cloud/directory-profile/fbd7d7d2/c463/4043/ac81/0bd52fb56369.jpg"
},
{
"resolution": "x300",
"imageUri": "https://api-downloads.usw2.pure.cloud/directory-profile/30900c29/3a64/4a09/9c32/7b65e8852144.jpg"
},
{
"resolution": "x400",
"imageUri": "https://api-downloads.usw2.pure.cloud/directory-profile/ffdff691/12c3/4241/8511/fc67a1037091.jpg"
}
],
"version": 23,
"acdAutoAnswer": true,
"selfUri": "/api/v2/users/15216105-d9dd-4e66-9b58-6d74f1b129eb"
},
{
"id": "ec63e2cf-0b6a-4c59-8adf-f67fe423ed58",
"name": "xxxxxxx xxxxxxx",
"chat": {
"jabberId": "xxxxxxxxxxxxxx@xxxxdxxx.orgspan.com"
},
"department": "Service Delivery",
"email": "@*******.com",
"primaryContactInfo": [
{
"address": ".@.com",
"mediaType": "EMAIL",
"type": "PRIMARY"
},
{
"address": "+1***",
"display": "+1 --",
"mediaType": "PHONE",
"type": "PRIMARY"
}
],
"addresses": [
{
"address": ".@.com",
"mediaType": "EMAIL",
"type": "WORK"
},
{
"address": "+1**********",
"display": "+1 --",
"mediaType": "PHONE",
"type": "WORK",
"countryCode": "US"
}
],
"state": "active",
"title": ", Service Operations",
"username": "@*.com",
"version": 20,
"acdAutoAnswer": true,
"selfUri": "/api/v2/users/ec63e2cf-0b6a-4c59-8adf-f67fe423ed58"
}
]

2

I was able to get the data action working "sort of" :grinning:
I am now getting back an array of data in the repsonse and need assistance with getting the supervisor name to show in the result window. Here is my current Translation map:

{
  "translationMap": {
    "name": "$.[0]name"
  },
  "translationMapDefaults": {},
  "successTemplate": "{\n   \"name\": ${name}\n}"
}

image854×536 11.8 KB

3

After much trial and error I was able to resolve the issue. I updated my output contract to the following:

{
  "title": "name",
  "type": "object",
  "properties": {
    "name": {
      "type": "string"
    }
  },
  "additionalProperties": true
}

And I updated the Translation Map to the following:

{
  "translationMap": {
    "name": "$.[0]name"
  },
  "translationMapDefaults": {},
  "successTemplate": "{\"name\": ${name}\n}"
}

Now everything is working properly.
